A130 -Knob Shaft-tube Assembly
Technical data
- Control System: HMI and PLC/PC
- Screen Display: machine commands, error codes, trouble shooting guide, and production statistics on HMI screen
- Machine Size (approx.): function of machine design
- Machine Weight (approx.): 1800kg (function of machine design)
- Power supply: 3 phase 220 V
- Air pressure: 6 bar
- Cycle time: 4 sec / assembly (function of machine design)
Products
Knob shaft assembly machines are customized to assemble the required components. Knob shaft consists of springs, O shape ring, shaft tube, square piece, and shaft sets. Bowl feeders feeding these parts in sequence one by one into each station. Only shaft sets are loaded into fixture by hand. Light curtain protects the safety of the operator while loading the parts. Finished assembled parts are unloaded to the slide one by one.
