RM100 -Pinhole Reaming
Technical data
  • Control System: HMI and PLC/PC
  • Screen Display: machine commands, error codes, trouble shooting guide, and production
      statistics on HMI screen
  • Machine Size (approx.): 250 cm x 210 cm x 190 cm
  • Machine Weight (approx.): 2200 kg
  • Power supply: 3 phase 220V
  • Air pressure: 6 bar
  • Cycle time: 4.5sec / 2piece
Products
Elevator, bowl feeder and linear transfer load 2 barrels to the ready position at the same time. Gripper will transfer the 2 barrels into the fixture of station 1. Station 2 will do the orienting work to make the barrels in right position. Then lock the 2 barrels at the right position. Each station will have a twin-head reaming unit. Each reaming unit will only ream one pinhole on the barrel. Totally, there are 5 or 6 reaming unit working at the same time but on different pinhole. After finishing the reaming work, the gripper will unload the barrels to the slide.
